Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16

Certification
China Guangzhou Yunki Hydraulic Mechanical Co., Ltd certification
China Guangzhou Yunki Hydraulic Mechanical Co., Ltd certification
I'm Online Chat Now

Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16

Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16
Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16
Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16

Large Image :  Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16

Product Details:
Place of Origin: Japan
Brand Name: Kawasaki KPM
Certification: ISO
Model Number: K3V180DT-1H2R-9N16
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden case
Delivery Time: 1-3 days
Payment Terms: T/T, Western Union
Supply Ability: 1000sets per month

Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16

Description
Product Name: K3V Hydraulic Main Pump Usage: Hydraulic Machinery Industry
Model: K3V180DT-1H2R-9N16 Application: Kato Excavator
Application Model: HD1880-7 Condition: Genuine Brand New
Weight: 195kgs Package Size: 98*50*63cm



Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16





Product Details



The hydraulic pump of an excavator is the core component of the hydraulic system of an excavator. The hydraulic pump converts the mechanical energy of the engine into hydraulic energy for transmission, and then converts it back into mechanical energy through hydraulic motors and hydraulic cylinders.



Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16
Product Name:
K3V Hydraulic Main Pump
Model Number:
K3V180DT-1H2R-9N16
Brand Name: Kawasaki KPM Place Of Origin: Japan
Condition:
Genuine Original New
Delivery:
Within 1-3 days after payment
Inventory:
In stock
Material: Casting Iron & Steel
Packing:
Wooden Case
Payment Term:
T/T, Western Union, Paypal
Application: Kato Excavator Application model: HD1880-7
Weight: 190KGS Dimension(L*W*H): 98*450*63cm
Warranty: 6 months After Warranty Service: Online support
Guarantee: We will check the pumps and send detail pictures to buyer to confirm before shipping.





K3V180DT Hydraulic Pump Spare Parts



We Provide New Kawasaki K3V280DTH Piston Pump Rotary Group, Replacement And Spare Parts, 100% Compatible With Original Kawasaki, Good Quality Piston Pump Parts And More Cost Effective Price. Spare parts include: Rotary Group, Drive Shaft, Support, Swash Plate, Yoke, Thrust Plate, Shoe Plate, Retainer Plate, Set Plate, Ball Guide, Piston Shoe, Pistons, Cylinder Block, Barrel, Valve Plate, Port Plate and other parts. Yunki is your aftermarket solutions partner for Kawasaki replacement piston pump parts. Precision piston pump parts can totally interchange with original Kawasaki, same specification and duration.



Item No. Name & Description QTY (pcs) Remark
1 K3V180DT DRIVE SHAFT 1 SHAFT
2 K3V180DT SUPPORT 1
3 K3V180DT SWASH PLATE 1 YOKE
4 K3V180DT THRUST PLATE 1 SHOE PLATE
5 K3V180DT RETAINER PLATE 1 SET PLATE
6 K3V180DT BALL GUIDE 1
7 K3V180DT COIL SPRING 1
8 K3V180DT PISTON SHOE 9 PISTONS
9 K3V180DT WASHER 1
10 K3V180DT CYLINDER BLOCK 1 BARREL
11 K3V180DT VALVE PLATE 1 PORT PLATE





Features



K3V series: K3V63, K3V112, K3V140, K3V180, K3V280

1. With new technology the K3V series has realized higher power density.

2. K3V series can cope with enlargement of displacement despite the same installation dimensions and regulator variations as K3V’s.

3. K3V series pumps have realized higher reliability and long life so as to meet requirement of larger torque.



Model K3V63 K3V112 K3V140 K3V180 K3V280
Displacement /cm3 63 112 140 180 280
Pressure MPa
(kgf/cm2)
Rated 34.3 (350)
Peak 39.2 (400)
Speed
/min-1
Max.for self priming 2,650 2,360 2,150 1,950 1,600
Max 3,250 2,700 2,500 2,300 2,300





ADVANTAGES



1. Long life.
2. High strength.
3. Easier for maintenance
4. More accurate.
5. Anti-corrosion.
6. Suitable for various environments.



Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 0

Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 1









 Excavator Hydraulic Pump/Swing Motor/Travel Motor Models



K3V Hydraulic pump: K3V63DT/ K3V63DTP, K3V112DT/ K3V112DTP, K3V140DT/ K3V140DTP K3V180DT/ K3V180DTH, K3V280DT/ K3V280DTH
K5V Hydraulic pump: K5V63/ K5V70DTP, K5V112DTP, K5V140DTP
MX Hydraulic motor: MX50, MX80, MX150, MX173, MX200, MX250, MX300, MX450, MX500,MX530, MX750
M2X Hydraulic motor: M2X55, M2X63, M2X96, M2X96, M2X120, M2X128, M2X146, M2X150,M2X210
M5X Hydraulic motor: M5X130, M5X160, M5X180
DNB Hydraulic travel motor: DNB50,DNB50B, DNB50V,DNB60B
HPV Hydraulic pump: HPV125B, HPV125A, HPVO55, HPVO102, HPVO91DW, HPVO91EW, HPV116C/D/F, HPV145, HPV145D, HPV145F
MAG Hydraulic Travel motor: MAG18, MAG26, MAG33, MAG44, MAG180, MAG150, MAG170, MAG85







We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.



Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 2



All of our Hydraulic Pumps are packed well in wooden case.



Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 3

Kato Excavator HD1880-7 Hydraulic Main Pump K3V180DT-1H2R-9N16 4
