Product Details:
|
Product Name: | High Pressure Piston Pump | Usage: | Excavator Hydraulic Parts |
---|---|---|---|
Model: | K3V112DT-IT3R-9C29-1 | Condition: | 100% New |
Application: | Kobelco Excavator | Application Model: | SK220-1 |
Material: | Casting Iron & Steel | HS Code: | 8413606090 |
High Light: | SK220-1 Hydraulic Pump,K3V112DT-IT3R-9C29-1 Hydraulic Pump |
SK220-1 Hydraulic Pump K3V112DT-IT3R-9C29-1 High Pressure Piston Pump
Product Details For High Pressuer Piston Pump
SK220-1 Hydraulic Pump K3V112DT-IT3R-9C29-1 High Pressure Piston Pump |
|
Product name: | High Pressure Piston Pump |
Model: | K3V112DT-IT3R-9C29-1 |
Brand Name: | KGM FLUTEK |
Place of Origin: | Japan |
Condition: | 100% New |
Material: | Good Quality Casting Iron + Steel |
Application: | Kobelco Excavator |
Usage: | Hydraulic Machinery Industry, Construction Machinery Parts |
Packing: | Wooden case |
Package Size: | 82X37X50CM |
Weight: | 150KGS |
Payment Term: | T/T, Western Union, Alipay, Wechat, Paypal |
Delivery time: | 1-3 Days after we received the payment |
After Warranty Service: | Online support and technical video support |
Warranty: | 6 months |
Guarantee: We will check the hydraulic pump and send detail pictures to buyer to confirm before shipping. |
K3V112DT Hydraulic Pump Spare Parts
We offer hydraulic pump spare parts for K3V112DT. Spare parts include: Drive Shaft, Support, Swash Plate, Set Plate, Ball Guide, Coil spring, Piston Shoe, Cylinder Block, Valve Plate and other parts. Yunki is your aftermarket solutions partner for Kawasaki replacement piston pump parts. Precision piston pump parts can totally interchange with original Kawasaki, same specification and duration.
Item No. | Name & Description | QTY (pcs) | Remark |
1 | K3V112DT DRIVE SHAFT | 1 | SHAFT |
2 | K3V112DT SUPPORT | 1 | |
3 | K3V112DT SWASH PLATE | 1 | YOKE |
4 | K3V112DT THRUST PLATE | 1 | SHOE PLATE |
5 | K3V112DT RETAINER PLATE | 1 | SET PLATE |
6 | K3V112DT BALL GUIDE | 1 | |
7 | K3V112DT COIL SPRING | 9 | |
8 | K3V112DT PISTON SHOE | 9 | PISTONS |
9 | K3V112DT WASHER | 1 | |
10 | K3V112DT CYLINDER BLOCK | 1 | BARREL |
11 | K3V112DT VALVE PLATE | 1 | PORT PLATE |
Features
1. With new technology the K3V series has realized higher power density.
2. K3V series can cope with enlargement of displacement despite the same installation dimensions and regulator variations as K3V’s.
3. K3V series pumps have realized higher reliability and long life so as to meet requirement of larger torque.
Model | K3V63 | K3V112 | K3V140 | K3V180 | K3V280 | |
Displacement /cm3 | 63 | 112 | 140 | 180 | 280 | |
Pressure MPa
(kgf/cm2)
|
Rated | 34.3 (350) | ||||
Peak | 39.2 (400) | |||||
Speed
/min-1
|
Max.for self priming | 2,650 | 2,360 | 2,150 | 1,950 | 1,600 |
Max | 3,250 | 2,700 | 2,500 | 2,300 | 2,300 |
Advantages:
1) The pump is better designed to provide more efficient and safer operation.
2) Our pumps are manufactured in Japan and designed to be more efficient than current designs.
4) We provide professional services that are cost-effective.
5) Increase operating efficiency by 3% with a high-quality, industrial-grade pump.
6) The K3V112DT-IT3R-9C29-1 hydraulic pump offers unparalleled performance and reliability while providing a generous warranty to back it up.
7) The quality of engineering improves with the assistance of this automated hydraulic pump.
We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.
All of our Hydraulic Pumps are packed well in wooden case.
