Product Details:
|
| Product Name: | K3SP36C Axial Piston Pump | Usage: | Hydraulic Parts |
|---|---|---|---|
| Model: | K3SP36C-1DAR-9003-8V | Condition: | 100% Genuine New |
| Application: | Liugong Excavator | Feature: | Compact Design |
| Material: | Casting Iron | HS Code: | 8413606090 |
| High Light: | Kawasaki Axial Piston Pump,K3SP36C-1DAR-9003-8V Axial Piston Pump,Liugong Excavator Axial Piston Pump |
||
Kawasaki Axial Piston Pump K3SP36C-1DAR-9003-8V For Liugong Excavator
Product Details
|
Kawasaki Axial Piston Pump K3SP36C-1DAR-9003-8V For Liugong Excavator |
|
| Product name: | K3SP36C Axial Piston Pump |
| Model: | K3SP36C-1DAR-9003-8V |
| Brand Name: | KPM |
| Place of Origin: | Japan |
| Condition: | 100% Genuine New |
| Material: | Good Quality Casting Iron + Steel |
| Application: | Liugong Excavator |
| Usage: | Hydraulic Machinery Industry, Construction Machinery Parts |
| Packing: | Wooden case |
| Package Size: | 40X40X40CM |
| Weight: | about 50 KGS |
| Payment Term: | T/T, Western Union, Alipay, Wechat, Paypal |
| Delivery time: | 1-3 Days after we received the payment |
| After Warranty Service: | Online support and technical video support |
| Warranty: | 6 months |
| Guarantee: We will check the hydraulic pump and send detail pictures to buyer to confirm before shipping. | |
K3SP36C Hydraulic Pump Spare Parts
We offer hydraulic pump spare parts for K3SP36C. Spare parts include: Drive Shaft, Support, Swash Plate, Set Plate, Ball Guide, Coil spring, Piston Shoe, Cylinder Block, Valve Plate and other parts. Yunki is your aftermarket solutions partner for Kawasaki replacement piston pump parts. Precision piston pump parts can totally interchange with original Kawasaki, same specification and duration.
| Item No. | Name & Description | QTY (pcs) |
| 1 | K3SP36C DRIVE SHAFT | 2 |
| 2 | K3SP36C BALL OF SWASH PLATE | 2 |
| 3 | K3SP36C SUPPORT | 1 |
| 4 | K3SP36C SWASH PLATE | 1 |
| 5 | K3SP36C TILTING PIN | 1 |
| 6 | K3SP36C SERVO PISTON | 1 |
| 7 | K3SP36C PISTON SHOE | 10 |
| 8 | K3SP36C SET PLATE | 1 |
| 9 | K3SP36C BALL GUIDE | 1 |
| 10 | K3SP36C COIL SPRING | 10 |
| 11 | K3SP36C CYLINDER BLOCK | 1 |
| 12 | K3SP36C VALVE PLATE | 1 |
Features
The K3SP36C swash plate variable piston pump for open hydraulic system, the total power control mode, used in construction machinery, especially suitable for 6 to 8 tons excavators. The piston pump has high pressure, compact design, light weight, wide range of applications, convenient installation, low noise and easy maintenance features.
| Model | K3SP36C |
| Displacement | 36x2 mL/r |
| Rotation(viewed from shaft end) | R:clockwise L:counter clockwise |
| Rated speed | 2000 r/min |
| Max. speed | 2300 r/min |
| Inlet pressure | 0.05~0.2 MPa |
| Rated pressure | 28 MPa |
| Max. pressure | 30 MPa |
| Recommend oil | L-HM46(summer) L-HM32(winter) |
| Housing pressure | ≤0.15 MPa |
| Gear pump displ. | 9 mL/r |
| Max. working pressure for gear pump | 5 MPa |
EXCAVATOR MODELS
LIUGONG: CLG904C CLG9045D CLG906 CLG907 CLG908 CLG909 CLG910 CLG915 CLG916 CLG918 CLG920 CLG922 CLG925 CLG926 CLG927 CLG933 CLG936 CLG939
LONKING : LG6060D L6065 LG6075 LG6085 LG6090 LG6150 LG6215 LG6225 LG6245 LG6285 LG6365
XGMA: XG804,XG806,XG808,XG809E,XG815,XG820,XG821,XG822,XG823,XG825LC,XG830,XG833,XG836LC,XG845,
XCMG : XE55D XE60D XE75D XE80D XE85C XE135D XE150D XE200C XE215 XE225 XE235 XE260 XE270 XE335 XE370 XE470 XE490 XE500
LOVOL: FR60 FR65 FR70 FR75 FR80 FR85 FR95 FR150 FR200 FR210 FR220 FR230F FR240 FR260 FR300 FR330 FR360 FR370 FR480
CATERPILLAR: 311C, 311DLRR, 312C, 312CL, 312D, 312DL, 313D, 314CLCR, 315CL, 315DL, 315D, 318CL, 318D, 320B, 320C, 320CL, 320D, 320DL, 321CLCR, 322D, 323D, 323DL, 324D, 326D, 325B, 325C, 325D, 329D, 329DL, 330B, 330C, 330D, 330CL, 330DL, 336B, 336C, 336D, 336DL, 345B, 345C, 345CL, 345D, 345DL, 349D, 349DL, 365C, 365CL, 374D, 374DL, 385C, 385CL, 390D, 390DL, 304CCR, 305.5, 305CCR, 305.5E, 305.5E2, 306, 306E, 306E2, 307, 307C, 307CSB, 307D, 307E, 307E2, 308, 308DCR, 308DCRSB, 308C, 308D,308E, 308E2, 313D2, 318D2, 320D2, 323D2, 326D2, 329D2, 330D2, 336D2, 349D2, 374F, 390F
We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.
All of our Hydraulic Pumps are packed well in wooden case.
