LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4

Certification
China Guangzhou Yunki Hydraulic Mechanical Co., Ltd certification
China Guangzhou Yunki Hydraulic Mechanical Co., Ltd certification
I'm Online Chat Now

LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4

LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4
LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4

Large Image :  LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4

Product Details:
Place of Origin: Japan
Brand Name: KPM
Certification: ISO
Model Number: K5V212-9NE4
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden case
Delivery Time: 1-3 days
Payment Terms: T/T, Western Union
Supply Ability: 1000sets per month

LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4

Description
Product Name: K5V KAWASAKI Piston Main Pump Type: Hydraulic Machinery Industry
Model: K5V212-9NE4 Application: Liugong Excavator
Application Model: LG950 Material: Cast Iron
Condition: 100% Original Brand New Feature: Low Noise
High Light:

LG950 Excavator Hydraulic Pump

,

K5V212-9NE4 Excavator Hydraulic Pump

,

K5V Main Pump Assy


LG950 Hydraulic Pump K5V KAWASAKI Piston Main Pump Assy K5V212-9NE4



Product Details


LG950 Hydraulic Pump K5V KAWASAKI Piston Main Pump Assy K5V212-9NE4
Product name:Kawasaki Hydraulic Piston Pump
Model:K5V212-9NE4
Brand Name:KPM
Place of Origin:Japan
Condition:100% Original Brand New
Material:Good quality Iron and Steel
Application:Liugong  Excavator
Applicable Model:LG950
Usage:Hydraulic Machinery Industry, Construction Machinery Parts
Packing:Wooden case
Package Size:98X50X63CM
Weight:about 250KGS
Payment Term:T/T, Paypal, Western Union, Wechat, Alipay
Delivery time:1-3 Days after received the payment
After Warranty Service:Online support and technical support
Warranty:6 months
Guarantee: We will check the hydraulic pump and send detail pictures to buyer to confirm before shipping.




K5V212 Hydraulic Pump Spare Parts

We offer hydraulic pump parts, range from K5V80, K5V140, K5V160, K5V200, K5V212. Spare parts include: Rotary Group, Drive Shaft, Support, Swash Plate, Yoke, Thrust Plate, Shoe Plate, Retainer Plate, Set Plate, Ball Guide, Piston Shoe, Pistons, Cylinder Block, Barrel, Valve Plate, Port Plate and other parts. Yunki is your aftermarket solutions partner for Kawasaki replacement piston pump parts. Precision piston pump parts can totally interchange with original Kawasaki, same specification and duration.


Item No.Name & DescriptionQTY (pcs)
1K5V212 DRIVE SHAFT/SHAFT1
2K5V212 SUPPORT1
3K5V212 SWASH PLATE/YOKE1
4K5V212 THRUST PLATE/SHOE PLATE1
5K5V212 RETAINER PLATE/SET PLATE1
6K5V212 BALL GUIDE1
7K5V212 COIL SPRING1
8K5V212 PISTON SHOE/PISTONS9
9K5V212 WASHER1
10K5V212 CYLINDER BLOCK/BARREL1
11K5V212 VALVE PLATE/PORT PLATE1




Features

K5V series: K5V80, K5V140, K5V160, K5V200, K5V212
The K5V series are variable displacement axial piston pumps of swash plate design, suitable for use in mobile applications such as Excavators, Cranes, etc. Various rotary group layouts, tandem type with PTO and parallel type are available to respond to applications. There are high reliability and more than 25 years of experience in the on mobile applications.


ModelK5V80K5V140K5V160K5V200K5V212
Displacement (cm3)80140160200214
Pressure (MPa)Rated34.3
Peak39.2
Max Self Priming Speed (min-1)2,4602,1602,000
[2,350]*1
1,850
[2,200]*1
2,000*1
StructureSingle-
Tandem-
Parallel -





LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 0
LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 1





We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.



LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 2



All of our Hydraulic Pumps are packed well in wooden case.



LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 3

LG950 Excavator Hydraulic Pump K5V Kawasaki Piston Main Pump Assy K5V212-9NE4 4
