Product Details:
|
| Product Name: | K3V180DTP Excavator Main Pump | Usage: | Excavator Hydraulic Spare Parts |
|---|---|---|---|
| Model: | K3V180DTP1FAR-9Y0A-V | Part Number: | KTJ11640 |
| Application: | SUMITOMO Excavator | Application Model: | SH460-5 |
| Material: | Casting Iron & Steel | Function: | High Efficiency |
| High Light: | K3V180DTP Excavator Main Pump,KTJ11640 Excavator Main Pump,SH460-5 Excavator Main Pump |
||
KTJ11640 K3V180DTP Excavator Main Pump K3V180DTP1FAR-9Y0A-V For SH460-5
Product Details
|
KTJ11640 K3V180DTP Excavator Main Pump K3V180DTP1FAR-9Y0A-V For SH460-5 |
|
| Product name: | K3V180DTP Excavator Main Pump |
| Model: | K3V180DTP1FAR-9Y0A-V |
| Part number: | KTJ11640 |
| Brand Name: | KAWASAKI KPM |
| Place of Origin: | Japan |
| Condition: | 100% Genuine Brand New |
| Material: | Good quality Casting Iron & Steel |
| Application: | SUMITOMO Excavator |
| Applicable Model: | SH460-5 |
| Usage: | Hydraulic Machinery Industry, Construction Machinery Parts |
| Packing: | Wooden case |
| Package Size: | 98*50*63CM |
| Weight: | about 195KGS |
| Payment Term: | T/T, Western Union, Paypal, Wechat, Alipay |
| Shiping method: | By air, by sea, by express (DHL/ UPS/ FEDEX) |
| Delivery time: | 1-3 Days after received the payment |
| After Warranty Service: | Online support and technical video support |
| Warranty: | 6 months |
| Guarantee: We will check the hydraulic pump and send detail pictures to buyer to confirm before shipping. | |
K3V180 Hydraulic Pump Spare Parts
We Provide Hydraulic Pump Spare Parts. Spare parts include: Rotary Group, Drive Shaft, Support, Swash Plate, Thrust Plate, Retainer Plate, Set Plate, Ball Guide, Piston Shoe, Cylinder Block, Valve Plate and other parts. Yunki is your aftermarket solutions partner for Kawasaki replacement piston pump parts. Precision piston pump parts can totally interchange with original Kawasaki, same specification and duration. 100% Compatible With Original Kawasaki, Good Quality Piston Pump Parts And More Cost Effective Price.
| Item No. | Name & Description | QTY (pcs) | Remark |
| 1 | K3V180 DRIVE SHAFT | 1 | SHAFT |
| 2 | K3V180 SUPPORT | 1 | |
| 3 | K3V180 SWASH PLATE | 1 | YOKE |
| 4 | K3V180 THRUST PLATE | 1 | SHOE PLATE |
| 5 | K3V180 RETAINER PLATE | 1 | SET PLATE |
| 6 | K3V180 BALL GUIDE | 1 | |
| 7 | K3V180 COIL SPRING | 9 | |
| 8 | K3V180 PISTON SHOE | 9 | PISTONS |
| 9 | K3V180 WASHER | 1 | |
| 10 | K3V180 CYLINDER BLOCK | 1 | BARREL |
| 11 | K3V180 VALVE PLATE | 1 | PORT PLATE |
Features
1. With new technology the K3V series has realized higher power density.
2. K3V series can cope with enlargement of displacement despite the same installation dimensions and regulator variations as K3V’s.
3. K3V series pumps have realized higher reliability and long life so as to meet requirement of larger torque.
| Model | K3V63 | K3V112 | K3V140 | K3V180 | K3V280 | |
| Displacement /cm3 | 63 | 112 | 140 | 180 | 280 | |
| Pressure MPa
(kgf/cm2)
|
Rated | 34.3 (350) | ||||
| Peak | 39.2 (400) | |||||
| Speed
/min-1
|
Max.for self priming | 2,650 | 2,360 | 2,150 | 1,950 | 1,600 |
| Max | 3,250 | 2,700 | 2,500 | 2,300 | 2,300 | |
Advantages
|
1. 100% Product quality protection
|
6.Mix color & design for you winner market
|
||
|
2. 100% On-time shipment protection
|
7.More than 10 years' manufacture for hydraulic spare parts
|
||
|
3. 100% Payment protection
|
8 .more than 10+ years for export experience
|
||
|
4.100% inspection before shipment
|
9.All products passed ISO9001
|
||
|
5. Most Popular "excavator parts" factory
|
10.One -stop service expariene more than 10+ years.
|
We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.
All of our Hydraulic Pumps are packed well in wooden case.
