TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V

Certification
China Guangzhou Yunki Hydraulic Mechanical Co., Ltd certification
China Guangzhou Yunki Hydraulic Mechanical Co., Ltd certification
I'm Online Chat Now

TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V

TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V
TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V

Large Image :  TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V

Product Details:
Place of Origin: Japan
Brand Name: KAWASAKI KPM
Certification: ISO
Model Number: K3V63DTP15LR-9C17-V
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden case
Delivery Time: 1-3 days
Payment Terms: T/T, Western Union
Supply Ability: 1000sets per month

TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V

Description
Product Name: TAKEUCHI Excavator Hydraulic Pump Assembly Usage: Excavator Hydraulic Spare Parts
Model: K3V63DTP15LR-9C17-V Application: TAKEUCHI Excavator
Application Model: TAKEUCHI J175 Material: Casting Iron
Condition: Genuine Brand New Function: Long Service Life
High Light:

TAKEUCHI J175 Excavator Hydraulic Pump

,

K3V63DTP15LR-9C17-V Excavator Hydraulic Pump

,

Excavator Hydraulic Pump Assembly

 TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V



Product Details


TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V

Product name: TAKEUCHI Excavator Hydraulic Pump Assembly
Model: K3V63DTP15LR-9C17-V
Brand Name: KAWASAKI KPM
Place of Origin: Japan
Condition: 100% Genuine New
Material: Good quality Casting Iron & Steel
Application: TAKEUCHI Excavator
Applicable Model: TAKEUCHI J175
Usage: Hydraulic Machinery Industry, Construction Machinery Parts
Packing: Wooden case
Package Size: 75*30*45CM
Weight: about 185KGS
Payment Term: T/T, Western Union, Paypal, Wechat, Alipay
Shiping method: By air, by sea, by express (DHL/ UPS/ FEDEX)
Delivery time: 1-3 Days after received the payment
After Warranty Service: Online support and technical video support
Warranty: 6 months
Guarantee: We will check the hydraulic pump and send detail pictures to buyer to confirm before shipping.




K3V63 Hydraulic Pump Spare Parts

We Provide Hydraulic Pump Spare Parts. Spare parts include: Rotary Group, Drive Shaft, Support, Swash Plate, Thrust Plate, Retainer Plate, Set Plate, Ball Guide, Piston Shoe, Cylinder Block, Valve Plate and other parts. 100% Compatible With Original Kawasaki, Good Quality Piston Pump Parts And More Cost Effective Price.


Item No. Name & Description QTY (pcs) Remark
1 K3V63 DRIVE SHAFT 1 SHAFT
2 K3V63 SUPPORT 1
3 K3V63 SWASH PLATE 1 YOKE
4 K3V63 THRUST PLATE 1 SHOE PLATE
5 K3V63 RETAINER PLATE 1 SET PLATE
6 K3V63 BALL GUIDE 1
7 K3V63 COIL SPRING 9
8 K3V63 PISTON SHOE 9 PISTONS
9 K3V63 WASHER 1
10 K3V63 CYLINDER BLOCK 1 BARREL
11 K3V63 VALVE PLATE 1 PORT PLATE




Features


K3V series: K3V63, K3V112, K3V140, K3V180, K3V280

1. With new technology the K3V series has realized higher power density.
2. K3V series can cope with enlargement of displacement despite the same installation dimensions and regulator variations as K3V’s.
3. K3V series pumps have realized higher reliability and long life so as to meet requirement of larger torque.


Model K3V63 K3V112 K3V140 K3V180 K3V280
Displacement /cm3 63 112 140 180 280
Pressure MPa
(kgf/cm2)
Rated 34.3 (350)
Peak 39.2 (400)
Speed
/min-1
Max.for self priming 2,650 2,360 2,150 1,950 1,600
Max 3,250 2,700 2,500 2,300 2,300





TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V 0

TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V 1




Advantages

1.Strong part number database.
If you can provide the right model and part number, we can supply the right product.


2.Professional and experienced salesperson.
Our founder has been into this field for more than 10 years, with rich experiences.


3.Strict and complete company rules.
We will try our best to meet customer’s delivery time. Before delivery, we must verify the part number or pictures of products one by one, to make sure that customers can receive high-quality and right-quantity goods.


4.Good management system.
No matter how big or small order, as long as customers place the order, we will provide exporting service free for charge.


5.Good service attitude.
If the customer has any questions about the product, In our receiving and knowing the situation, we will help the customer to solve the problem in the first place.As long as customers’ requirements are reasonable, we will endeavour to make them satisfied.





We offer wide range of hydraulic pumps that can suit to excavator such as Komatsu, Caterpillar, Hitachi, Kobelco, Mitsubishi, Hyundai, Volvo.



TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V 2



All of our Hydraulic Pumps are packed well in wooden case.



TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V 3

TAKEUCHI J175 Excavator Hydraulic Pump Assembly K3V63DTP15LR-9C17-V 4
